ESR type without AC-DC converter

SR - SR12 with AC input power

SR24 - 60 with AC input power

Light signaling of obstacles to air navigation are critical applications and require reliable, fail-safe equipments so that they can prevent and alert of danger to the aircraft pilot. The equipment must meet the specifications of the Aeronautics, ANAC, ICAO, CAA and FAA standards.

Sunlab Power® Air Obstacle Beacons are manufactured with high quality materials and technology, to allow an effective result.

Application:

  Obstruction light can be installed to any high structure, as well as towers, constructions, aerial cables and some other objects whose can be less visible to the pilot at short distance, such as telecom and transmission towers, elevated water tanks, lighthouses, cranes, chimneys and wind turbines. Shorter structures that are located close to airports also require obstacles lights.

   The presence of obstacles which need to be lightened must be indicated by lights of low, medium, and high intensity or a combination of such lights. They are usually arranged in clusters around the structure at specific heights. Often there will be one set at the top and then one or more sets equally spaced by the frame, in position to define the general shape of the object.

   Installing beacon groups may require synchronized flashes. Sunlab Power® supplies the entire system, including photovoltaic generators, UPS and AC/DC converters, with fault protection and supervision.

Characteristics:
 SunLab Power^® AOB models are compliant to ICAO types, design and performance, and has the advantages:

    > Aluminum body: compact and light without reducing the functionality.

    > Low power consumption. Customizable for AC and DC power input.

    > Electronic circuit includes fail safe, over power and surge protections.

    > Photo sensor incorporated for switch on and off automatically.

    > Fresnel lens in Makrolon^®: corrosion, U.V. and I.R. resistant.

    > Does not need ballast as discharge lamps.

    > Flex powered: input AC or DC, solar, grid power or hybrid available.

Advantages:

    > Low maintenance or replacements

  > Minimal loss of luminous flux

  > High resistance to temperature changes, snow, vibrations.

  > Flashes don't reduces the life of LED.

Low

Intensity Lights

Operational Time x Intensity

Intensity

Class

Model

Type

Light

Color

Flash

FPM

Part

Number

Daytime

(cd)

Twilight

 (cd)

Nightime

(cd)

Typical Application

SR1

A

Red

980.V01-

032

-

-

≥10

- Fixed obstacles not exceed 45 meters height.

- Non-extensive obstacles.

- Helidecks (CAA-CAP437)

ES2R/

SR2

B

Red

Steady

980.V03-

032

-

-

≥10

- Obstacles not exceeding 45 meters height.

- In combination with other medium intensity.

ES4R/

SR4

B

Red

Steady

980.V05-

032

-

-

≥32

- Obstacles not exceeding 45 meters height.

- Low intensity type B can be used in combination with type B medium intensity lights.

E

Red

Flash

40

981.V05-

032

-

-

≥40

- Wind turbines.

C

Yellow

Flash

60-90

981.V05-

034

-

≥40

≥40

- (Follow-me) Moving objects

Blue

981.V05-

036

-

≥40

≥40

- Applied to moving objects.

V = Input Voltage (see codification)

Medium

Intensity Lights

Intensity

Class

Model

Type

Light

Color

Flash

FPM

Part Number

Daytime

(cd)

Twilight

 (cd)

Nightime

(cd)

Typical Application

ES24R/

SR24

A

White

Flash

20-60

981.V20-

030

20.000

± 25%

20.000

± 25%

2.000

± 25%

- In conjunction with high intensity signaling, at intermediate heights of less than 150 meters, with separation not exceeding 105 meters.

- Additional lights at intermediate, evenly spaced levels.

- Extensive objects as a group of buildings.

- Wind turbines with a total height greater than or equal to 150 meters and less than or equal to 315 meters.

ES12R/

SR12

E

981.V10-

030

-

-

2.000

± 25%

ES12R/

SR12

B

Red

Flash

20-60

981.V10-

032

-

-

2.000

± 25%

- Obstruction with a height greater than 45 meters and less than 150 meters or extensive as a group of buildings.

- The separation should not exceed 52 meters.

- Use alone or in combination with low Intensity type B lights.

- Add in intermediate levels, alternately of low intensity type B and medium intensity type B, spaced most evenly.

C

Red

Steady

980.V10-

032

-

-

2.000

± 25%

- Used alone or with additional lights at intermediate levels spaced as evenly as possible.

- When dealing with large objects or a group of buildings.

V = Input Voltage (see codification)

High

Intensity Lights

Operational Time x Intensity

Intensity

Class

Model

Type

Light

Color

Flash

FPM

Part Number

Daytime

(cd)

Twilight

 (cd)

Nightime

(cd)

Typical Application

ES60R

SR60

A

White

Flash

40-60

981.V30-

030

200.000

± 25%

20.000

± 25%

2.000

± 25%

- Obstruction whose height is equal to or greater than 150 meters.

ES50R

SR50

B

981.V25-

030

100.000-

± 25%

20.000

± 25%

2.000

± 25%

- Electrical lines towers, suspended cables or similar objects configuration.

V = Input Voltage (see codification)

High & Medium

Intensity Beacons Conjugated

Operational Time x Intensity

Intensity

Class

Model

Type

Light

Color

Flash

FPM

Part Number

Daytime

(cd)

Twilight

 (cd)

Nightime

(cd)

Typical Application

ES60R

/SR60

A

White

Flash

40-60

981.V20-

130

200.000

± 25%

20.000

± 25%

2.000

± 25%

- Obstruction whose height is equal to or greater than 150 meters.

- Power line support towers, overhead cables or objects of similar configuration.

It can be programmed for simultaneous operation or in specific situations. Generally used as:
a) Redundancy: If one fails, the other goes into operation.
b) Simultaneous: To increase visibility.

ES50R

/SR50

981.V25-

130

100.000-

± 25%

Flash

20-60

981.V26-

230

20.000

± 25%

20.000

± 25%

ES12R/

SR12

2.000

± 25%

TABLE 2 - Electrical Characteristics

Model

ES2R

SR2

ES4R

SR4

ES12R

SR12

ES24R

SR24

ES60R

SR60

Current max. (A)

0,42

0,04

0,58

0,06

1,16

0,12

1,12

0,22

3,75

0,71

Consumption max. (Watts)

5,0

5,0

7,0

7,0

14,0

14,0

27,0

27,0

90,0

90,0

Input Power (V)

12

100-270

12

100-270

12/24

100-270

24

100-270

24

100-270

On/Off

Automatic - photo sensor incorporated

EMI/RFI

No interferences emission

M.T.B.F.

100.000 hour

TABLE 3 - Construction Characteristics

Lighting Emitter

LED - Power LED

Body

In cast aluminum with electrostatic paint.

Lens

Makrolon^®

Moisture

98%

Temperature resistance

-30°C + 75°C

Fix

Female thread 3/4"

Isolation IEC529 st

IP65

Dimensions (mm.)

210 H x 105 ø

Weight

~ 1,50  Kg

Guaranty

2 years
